Auto Nitrogen Cabinet 1%~60%RH

Basic info

Description

Auto Nitrogen Cabinet is mainly used for protecting the humidity sensitive electronics from moisture damage and oxidation,such as optical and electronic components,printed circuit boards, optical film and lens, LED,PCB board, crystal, SCR,IC, BGA,Silicon wafer and other sophisticated electronic devices.

JAYON Nitrogen Cabinet can save 70% of N2.It has N2 flow sensor and calibration capabilities of the sensor. All nitrogen cabinets comply with J-STD-033C standard.

Reference humidity for various articles storage:

Options:

• Oxygen content sensor
• Data Logger with USB port
• Open door signal alarm
• Over humidity signal alarm
• Extra shelves

Details

Features

• Humidity Range: 1~60%RH (adjustable)
• Display Precision: ±3.0%RH,  ±1.0℃
• Chamber adopts High grade 1mm and 1.2mm cold rolled steel plate, reinforced structure design,excellent load-bearing and sealing performance.
• LED Digital display panels, using US import Honeywell humidity sensor; temperature and humidity independent display. Humidity can be set and has a memory function, power failure no longer set.
• Surface treatment with Dupont orange line baking varnish which is strong corrosion resistance to avoid the stored goods from pollution,static shock, and oxidation..
• 3.2mm high intensity toughened glass.
• Zinc alloy lock with air tightness,with anti-theft function.
• Install ESD casters with brakes for easy move and ESD stand.
• Power supply: AC power 85V~265V 50/60Hz;
• With two types black surface (anti-static type) or White surface(nonanti-static type)
• Equipped with the nitrogen gas input connection and nitrogen flowmeter, the system will automatically cut off the nitrogen supply when humidity in the cabinet achieves the setting value. When more than the setting value, the system will automatically open nitrogen supply. Compared to other Nitrogen cabinets, it can save 70% nitrogen consumption.

Specifications
